Power your home with confidence using the Jackery Explorer 5000 Plus! With a capacity of 5-60kWh and 7.2-14.4kW output, this reliable backup power source can last up to 2 weeks. Its dual voltage option supports a variety of loads and it can fully charge in just 1.7 hours. Enjoy uninterrupted power with UPS 0 ms switchover and advanced protection from ChargeShield 2.0. With a next-gen LiFePO4 battery and smart app control, this compact and quiet design will provide reliable power for over 10 years. Don't miss out on the 5-year warranty, with an option for an additional 2 years!
- 5-60kWh Capacity & 7.2-14.4kW Output for reliable home backup power lasting up to 2 weeks.
- 120V/240V dual voltage enhances compatibility, supporting more loads like dryers, water pumps, ovens, ACs, EVs, RVs, etc.
- Fully charges in 1.7 hours, compatible with AC, high-voltage PV (4000W, 135-450V), low-voltage PV (1200W, <60V), and more.
- UPS 0 ms switchover for uninterrupted power to essential devices.
- Next-gen LiFePO4 battery lasts over 10 years, including a 5-year warranty 2 optional years.
- ChargeShield 2.0 for advanced protection and efficient charging.
- Smart App Control: Remotely monitor and manage power usage, with scheduled charge/discharge settings for efficiency.
- Compact & Quiet Design: Features optimized CTB structure, equipped with wheels and a pull handle, maintaining a low noise level of just 30 dB.
- Solar Integration: Connects with Jackery 500X solar panels, 25% higher efficiency.
- Founded in 2012 in California, Jackery has earned the trust of over 4 million users and received more than 150,000 positive reviews.
Battery
Capacity: 45Ah/112V DC (5040Wh)
Cell Chemistry: LiFePO4
Cycle Life: 4000 cycles to 70% capacity
Ports
AC Output: (NEMA L14-30R/14-50) 120V/240V~60Hz, 30A, 7200W Max
AC Total Output: 7200W Max, 14400W Surge
AC Output(x4): 120V, 20A, 2400W
USB-A Output(x2):1 8W Max, 5-6V⎓3A, 6-9V⎓2A, 9-12V⎓1.5A
USB-C Output(x2): 100W Max, 5V⎓3A, 9V⎓3A, 12V⎓3A, 15V⎓3A, 20V⎓5A
Cigarette Lighter Port: 12V⎓10A
AC Expansion Port (Output)(x1): 240V~60Hz, 30A, 7200W
DC Expansion Port (Output)(x1): 80.5V-126V⎓41A Max
Charge mode AC input: 120V~60Hz, 15A Max
Bypass mode AC input/output: 120V, 12A Max 240V, 16.7A Max
AC Expansion Port (Input)(x1): 240V~60Hz, 16.7A Max
DC Expansion Port (Input)(x1): 80.5V-126V⎓98A Max
High-PV: 135V-450V⎓15A Max
Low-PV: 2 x DC 8mm Ports; 16V-60V⎓10.5A Max, Double to 21A/1200W Max
11V-16V(Working Voltage)⎓8A Max, Double to 8A Max
11V-16V(Working Voltage)⎓8A Max, Double to 8A Max
Dimensions
Weight: About 134.5 lbs
Height: 16.5in
Width: 15.5in
Length: 25 in
Charging Time(0-100%)
AC Adapter: 3.5 Hours
Solar Panel: 2 x SolarSaga 500W Solar Panel 1000W, 6.5 hours
General
Warranty: 5 Years
Charge Temperature: 32°F~113°F
Discharge Temperature: 5°F~113°F
UPS:Backup UPS: ＜20ms, Onine UPS: 0ms
Inverter Topology: Non-isolated
Power Factor: ≥0.98
Entire Unit: Type 1
